MEASUREMENT
RANGES
| Mode | Velocity
| Transit time
| Elastic Modulus
|
| Range | 1 to 9999
| 0.1 to 9999㎲
| up to 999.9
|
| Units | m/s or ft/s
| 2 ranges 0.1 or 1㎲
| GN3㎡
|
| Accuracy | ± m/s of ft/s
| ±0.1㎲
| ±0.1 GN/㎡
|
| Over Range | Indicated by over range message |
| Lost Signal | Indicated by lost signal message |
| DISPLAY | 128×128 dot LCD with back lighting |
| RS232C
OUTPUT
| Baud Rate | Fixed at 9600 baud |
| Parity | None |
| Data Bits | 8 |
| Stop Bits | 1 |
|
SCOPE OUTPUT
| Synchronisation pulse
| 3.5V positive, rise time 2㎲ |
| Signal | True facsimile of receiving transducer output for outputs up to 0.4V. For outputs in excess of this value the receiving transducer may be
plugged directly into the CRO add-on unit with the time base sync-
hronised from the instrument
|
| TRANSMITTER | Energising Pulse | Nominal 1.2kV, 500V or 250V , 1.5㎲ duration |
| POWER SUPPLY | Battery | Internal rechargeable NiMH batteries 8×1.2V/ 1.2Ah |
| Power supply | 100/ 240V AC input 50/60Hz. 20V DC output |
| ENVIRONMENTAL
| Range | 0℃ to 40℃(Operating Temperature) |
| Dimensions | 250×160×100mm |
| Weight | 2.3kg electronics unit only |
| Complete Kit | 8.2kg |
| OPTIONAL EXTRAS | A range of transducers and amplifiers are available |
